MORIMOTO | Reverse Light: Backup Light Boost Bar | LED700

Name: MORIMOTO | Reverse Light: Backup Light Boost Bar | LED700
Brand: MORIMOTO LIGHTING
Price: 140.00 CAD
Availability: InStock

SKU: SKU: LED700

Fits your vehicle

$140.00

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

Free Shipping in Canada over $350!
Expedited shipping across Canada!
Expert Fitment & Product Support
CALL/TEXT 416-624-1357

View full details

Description

High Output: While there are plenty of LED bulb upgrades out there for stock reverse lights; when it comes to a backup light boost that will compliment your Morimoto XB LED tail lights, this is a no brainer. The BLBB bolts on. It's Plug n Play. It generates maximum output... in reverse! Easy Setup: If you're running a set of the new Morimoto XB tail lights with the Backup Light Boost connection, these will be super easy to install since the input connector will plug n play with the reverse light circuit wiring on the back of your tail lights. No Backup Light Boost connection? No problem. The system includes 1.5 meters of integrated wiring and a high-quality tap kit to draw 12V from your factory reverse light harness. An integrated rubber grommet keeps moisture and dust out of a pass-through hole if necessary too. Bolt-On: The Backup Light Bar will bolt onto your vehicle's top two license plate mounts. Its die-cast aluminum housing is contoured according to the geometry of US-spec license plates for a flush fit, and the mounting points are positioned according to the same universal standard. The system is finished in a satin black powder coat. Optically Advanced: The Morimoto Backup light boost light bar relies on a combination of optical refinement and raw power to produce the perfect reverse light beam pattern. Morimoto's optical engineering team optimized the lens to distribute the most possible light in the most effective beam pattern based on typical surface mounting angles. This is a fully engineered product, and that shows in the results. Technically Speaking: At a 10-degree mounting angle, the vertical range is -20 to +25 degrees. At the most typical 0-degree mounting angle, the Morimoto Reverse Light Bar provides a -30 to +15 degree vertical spread, which easily exceeds the illumination range of any standard backup for spread. Though great to experience, its worth noting that the output produced by this product far exceeds the legal limit for a reverse light application. Tech Specs: 45 CREE J Series 2835 LEDs rated at 4500K/80CRI. 180mA driver produces 29.9W of maximum power pumps out 2700 raw lumens that's translated into 1950 real lumens after transmission through the optical lens.

Features & Specifications

Intensity: 2,700lm (Raw), 1,950lm (Effective)
Power: 29w
Optic: -30deg to +15deg vertical range
Light Source: 45X CREE J 4500K (Warm White)

What's Included

Reverse Light: 1x Morimoto Backup Light Boost Bar
Wiring: 1x Power Tap Kit

Vehicle Compatibility & Important Notes

Plug n Play: With 'Backup Light Boost' enabled Morimoto XB Tail Lights
Universal Setup: All 9-16V Reverse Light Circuits (w/ Wire Taps)
License Plates: US-Spec Plate Mounts (excl. 19+ Ram 1500 due to bumper shape)

Product Details

Package Dimensions: 13 × 2 × 1 in
Package Weight: 0.6 lb

Warranty: Five (5) Years

➡️ Warranty

Morimoto Warranty

Product Warranty Term: Five (5) Years

Morimoto warranties are non-transferable, apply only to the original purchaser, and are calculated from the original purchase date. A replacement product does not reset or extend the original warranty period.

Warranty Claims: For products purchased from an authorized dealer, contact the dealer from whom the product was purchased for claim instructions. Troubleshooting may be required to identify the failed component and determine the appropriate replacement. Certain products, including headlights, tail lights, and LED pod lights, may need to be returned if they cannot be serviced remotely.

Exclusions: Warranty coverage does not apply to products that have been physically damaged or modified, including damage from tampering, misuse, accidents, or alterations. Warranty coverage applies to the product itself and does not cover labor, installation charges, rental vehicles, downtime, or other related expenses.

Components & Discontinued Products: When a component within a kit or assembly fails, Morimoto may replace the affected component rather than the complete system. If a product has been discontinued, a current equivalent may be offered; if no equivalent exists, store credit equal to the original amount paid may be issued.

Warranty Replacement Shipping: Customers outside the United States are responsible for warranty replacement shipping costs and duties. Expedited replacement shipping, when requested, is charged at actual cost.

Warranty eligibility and claim handling remain subject to Morimoto's current warranty terms and the product-specific coverage applicable to the item.
