ICON VEHICLE DYNAMICS | 07-18 Jeep JK 3 Inch Stage 3 Suspension System Icon Vehicle Dynamics | K22003

The ICON Vehicle Dynamics 3 Inch Lift Suspension System is designed for Jeep JK owner's demanding the ultimate in performance and ride quality, without the larger stance you find in bigger lift systems on today's market. ICON's Jeep Wrangler JK 3 Inch lift system is engineered with front and rear dual rate progressive wound springs which is the foundation for on and off-road performance and suspension articulation.

The dual rate design gives you a softer initial rate for superb on road comfort and a firmer than stock secondary rate that increases during compression for excellent bottom out control. ICON V.S. 2.0 Aluminum Series Remote Reservoir shocks add the finishing touch with OE mounting, aircraft grade components, and vehicle specific valving.

Remote Reservoir shocks are great for additional heat dissipation to prevent shock fade during off road use. Together the combination of ICON dual rate coils and V.S. 2.0 Aluminum Series shocks adds 30 Percent more wheel travel over stock, helping you rock crawl safer or soak up larger terrain at higher speeds keeping those wheels on the ground.

In this Stage 3 system adjustable track bars are included front and rear for optimizing axle position to ensure your axles are perfectly centered under the vehicle. This ICON 3 Inch JK lift system is designed from the ground up to give the Jeep Wrangler JK's the best performance, suspension handling / ride quality, and clearance for 33 Inch tall tires (35 Inch tall with installation of aftermarket high-clearance fenders).

Features and Benefits:

• Dual Rate Coil Springs Front and Rear
• Adds 30 Percent More Wheel Travel over Stock
• Vehicle can be Returned Back to Stock
• No Welding or Cutting
• Includes High Performance Rebuildable / Revalvable Remote Reservoir 2.0 Aluminum Series Shocks
• Out Articulates Most Long Arm Kits of Comparable Height
• Includes Adjustable Track Bars for Optimized Axle Positioning
• Track Bars include Dual Stage Bushing System and JM12T Rod End to minimize deflection while maximizing responsiveness
• Lifetime Guarantee that Coil Springs Won't Sag

Details

• Bushings Included: Yes
• Coils Quantity Front: 2.0
• Coils Quantity Rear: 2.0
• Dual Rate Coil Springs: Yes
• Grade Type: Performance
• Maximum Lift: 3.0 Inch
• Mounting Hardware Included: Yes
• Oem Wheels & Tires Fitment: Yes
• Recommended Aftermarket Tires: 33 Inch X 11.50 Inch (Larger 35 Inch Tire Packages Will Fit With Minor Modifications Or Aftermarket High Clearance Fenders, Test Fitment Recommended)
• Recommended Aftermarket Wheels: Icon Alloys - 20x9 Inch W/ 4.5 Inch Backspace / -12mm Offset, Icon Alloys - 18x9 Inch W/ 4.5 Inch Backspace / -12mm Offset, Icon Alloys - 17x8.5 Inch W/ 4.5 Inch Backspace / -6mm Offset
• Shocks Included: Yes
• Spring Color: Black
• Spring Material: Steel
• Add On Part: 22014 - 12-18 JK Front Driveshaft W/Yoke Adapter 2.5-6 Inch Lift, 191014 - .25 Inch Collar Spanner Pin Wrench, 252012 - -4 To -10 Hose Shield Kit, 22016 - 07-11 JK Front Driveshaft W/Yoke Adapter 2.5-6 Inch Lift, 22039 - 07-18 JK 2.0 Centerline Stabilizer Kit, 22042 - 20-Up JT / 18-Up JL / 07-18 JK Front Hyd Bump Stop Kit, 22011 - 12-Up JK Exhaust Spacer Kit, 22020 - 07-18 JK 2.0 Centerline Stabilizer Kit Adjustable, 252008 - 2.5 X 13 Shock Boot Black (Pair)
